Thickness – Sandwich structure
From bottom to top: 1. model with 2 topologically matching meshes – outer (by extruding inner and deleteing all but the original faces) | inner 2. Sandwich structure rebuilt by…
Polygon division by polygon offset
Testing a simple method of mesh face division by polygon offset using current implemetation of polygon related functions – offset, convertion to polyline, polyline division and basic 2d delaunay triangulation….
mesh face offset by vertex color 2
All vertices in face are aligned and project to xzplane from its best fit plane for the 2d offset operation then converted back therefore resulting offset holes are always planar….
vector | polygon mesh
1. iterative vector regular distrubtion 2. polycut 3. rebuild polygon mesh at face center
